Low-Voltage High-Flexibility Micro Servo Cable Power Cable

シリアルコード : A0210010S 製品コード : Round Cable-RVV

Applications:

Suitable for use as a connecting and control cable in both dry and wet indoor environments—particularly in electronic installations under industrial conditions. With a conductor cross‑section of 0.5 mm² or larger, this cable supports control and interconnection functions in:

  • Machine tool manufacturing
  • Complete equipment installation
  • Power stations
  • Ventilation and air‑conditioning systems

Its enhanced flexibility also makes it well‑suited for installations requiring routing in confined spaces or where occasional movement occurs.



Key Properties:

PVC (polyvinyl chloride) insulation delivers a combination of high mechanical strength, excellent electrical insulation, strong chemical stability, and reliable water resistance—making it a durable and versatile choice for industrial cable applications.

Cables featuring color-coded core identification further enhance installation accuracy, operational safety, and maintenance efficiency, supporting reliable long-term performance in demanding environments.





Conductor material

Bare Copper (according to DIN EN 60228)

Conductor design

IEC 60228 class 6

Core identification

Numbers

Colors

Core insulation

PVC

Core stranding

Cores wound with an optimised pitch length.

Shielded

No

Outer jacket

PVC

Outer jacket color

Black RAL9005

Grey RAL7001

Product type

Installation cable

Application area

Fixed Installation

Nominal voltage

<0.5mm²:U0/U 300/300V

0.5mm²-4.0mm²:U0/U 300/500V

≥4.0mm²:U0/U 450/750V

Test voltage

<0.5mm²:1500V

0.5mm²-4.0mm²:2000V

≥4.0mm²:2500V

Temperature, fixed

-15°C to +70°C (according to DIN EN 50305)

Min. bend radius, fixed

6 x OD

Lead-free

According to 2011/65/EU (RoHs-II/RoHS-III)

NFPA

According to NFPA 79-2018

PTFE-free

The design of these products does not contain PTFE

PWIS-free

According to VDMA 24364-B2-L

REACH

According to (EC) No. 1907/2006 (REACH)

Silicone-free

According to PV 3.10.7 – status 1992

Laboratories and Test Centers

In our laboratories, we evaluate the long‑term effects of environmental factors — including UV exposure, rain, ozone, seawater, oils, and cleaning agents — on the materials used in our products.

Within our dedicated test facilities, we conduct rigorous performance assessments such as:

  • Electrical transmission and signal integrity verification
  • Service life and endurance testing
  • Continuous load validation under demanding conditions
  • Fire behavior and flame‑resistance analysis

These comprehensive tests directly inform the design and manufacturing of future Anyang® products.  Our multi‑stage validation processes ensure not only compliance with industry standards and legal requirements, but also support our commitment to sustainability and environmental regulations — including REACH and RoHS — through verified material safety and product reliability.



Validated Through Rigorous Testing

Not all tests deliver the same level of assurance.  Only the most demanding evaluations can verify true performance under real‑world conditions.  That is why every product and material undergoes stringent validation in our specialized testing centers.

We assess practicability, durability, and compatibility across diverse application environments—ensuring that each solution meets the precise needs of our customers.  Upholding this commitment is a responsibility we take seriously: to deliver on our promise of consistent, reliable, and high‑quality connectivity.

  • RoHs 2.0

    RoHs 2.0

  • Reach

    Reach

  • ISO 9001

    ISO 9001

  • UL

    UL

  • TÜV

    TÜV

  • VDE

    VDE

Testing video

Speed, Reliability, and Flexibility: The Pillars of Anyang Logistics

In today’s global market, logistics demands speed, reliability, and flexibility—standards that Anyang meets through a state-of-the-art, fully integrated network of logistics and service centers.

Beyond fast and dependable cable shipment, we provide a comprehensive suite of logistics products and services designed to streamline your operations.  Our portfolio includes tailored transport, storage, and unwinding solutions that enable efficient cable handling and integration into your workflow.

These capabilities not only enhance supply chain performance but also drive tangible process efficiencies—helping you stay agile and competitive in a rapidly evolving marketplace.

Packing details

Wooden Roll
Wooden Roll

Roll
Roll

Shipping Package
Shipping Package
